Our range of signal conditioners is designed for operation with our different sensors.
In general, the signal conditioner interfaces with a sensor and performs all required signal processing in order to provide a current or voltage signal suitable for transmission to the monitoring system.
-
- IPC707 signal conditioner
- Signal conditioning for CA accelerometers and CP dynamic pressure sensors.
- Vibration or dynamic pressure measurement for machinery protection and/or advanced condition monitoring.
- Very wide frequency range (0.5 to 20000 Hz), with configurable high-pass and low-pass filters, independent of transfer function.
- Configurable transfer function (sensitivity and units), with optional integrator to provide a velocity output.
- Current output for long-distance signal transmission or voltage output for medium-distance signal transmission.
- Certified for use in potentially explosive atmospheres (Ex) and/or safety-related applications (SIL).
-
- IQS900 signal conditioner
- Signal conditioning for TQ proximity sensors.
- Shaft relative vibration and gap/position measurement for machinery protection and/or advanced condition monitoring.
- Very wide frequency range (DC to 20000 Hz), with configurable sensitivity and measurement range.
- Current output for long-distance signal transmission or voltage output for medium-distance signal transmission.
- Certified for use in potentially explosive atmospheres (Ex) and/or safety-related applications (SIL).
- Fully compliant with API 670 5th edition.
-
- IQS910 signal conditioner
- Signal conditioning for TQ proximity sensors.
- Position (gap) or vibration (shaft relative) measurement for machinery protection and/or basic condition monitoring.
- Wide frequency range (DC to 15000 Hz), with configurable measurement type (position or vibration), sensitivity and measurement range.
- Position measurement or vibration measurement with “peak-meter” vibration processing.
- Industry-standard 4 to 20 mA current-loop output.
- Certified for use in potentially explosive atmospheres (Ex) and/or safety-related applications (SIL).
-
- ILS730 signal conditioner
- Signal conditioning for the LS120 air-gap sensor
- Enhanced filtering of noise and spikes induced by high excitation currents
- Voltage outputs: minimum gap, rotor profile and pole profile
- Configurable current loop output: minimum gap, rotor profile or pole profile
- Current output for signal transmission over long distances and voltage outputs for signal transmission over medium distances
-
- ILS731 signal conditioner
- Signal conditioning for the LS121 air-gap sensor
- Enhanced filtering of noise and spikes induced by high excitation currents
- Voltage outputs: minimum gap, rotor profile and pole profile
- Configurable current loop output: minimum gap, rotor profile or pole profile
- Current output for signal transmission over long distances and voltage outputs for signal transmission over medium distances
-
- DIC413 signal conditioner and de-icing controller
- Signal conditioning and de-icing control for the EW140 ice-detection sensor
- Voltage output: ice thickness
- Relay outputs: OK and ice alarm
- Voltage output for signal transmission over medium distances and relay outputs for indication and control
- Certified for use in potentially explosive atmospheres
