• VibroSmart® VSV301 monitoring module
    • VibroSmart® VSV301 monitoring module
    • VibroSmart® VSV301 monitoring module
      • 2 dynamic channels and 1 auxiliary channel (tachometer or DC input)
      • Up to 20 processed outputs per module (for the 2 dynamic channels, 1 auxiliary channel and 1 dual-shaft relative channel)
      • Highly configurable module supports simultaneous data acquisition on all channels, with asynchronous/synchronous sampling depending on the processing
      • 24-bit data acquisition, high SNR data processing, with a high-resolution FFT up to 1600 lines every 1 s
      • Highly integrated module (with VSB300 terminal base) includes sensor power supplies, buffered outputs, DC outputs, relays and Ethernet communications interfaces
    Compare
  • VibroSmart® VSI010 communications interface module
    • VibroSmart® VSI010 communications interface module
    • VibroSmart® VSI010 communications interface module
      • Up to 2 serial fieldbus interfaces (Modbus RTU or PROFIBUS DP) or 1 Ethernet fieldbus interface (Modbus TCP)
      • PROFIsafe safety layer to ensure more reliable PROFIBUS communications
      • Acts as a data communications bridge between VSV30x modules and third-party systems such as a DCS or PLC over industry standard fieldbuses
      • 8 basic and 4 advanced logic functions to combine alarm and status information from VibroSmart modules in the same measurement block
      • Two VSI010 modules can be used in the same measurement block to support redundant operations
    Compare
  • VibroSmart® VSB300 terminal base for VSV30x module
    • VibroSmart® VSB300 terminal base for VSV30x module
    • VibroSmart® VSB300 terminal base for VSV30x module
      • Input/output (interface) terminal base for a VSV30x module – supports 2 dynamic channels and 1 auxiliary channel (tachometer or DC input)
      • Differential signal input with sensor power supply output per dynamic channel and per auxiliary channel
      • Differential buffered (raw) transducer output per channel
      • DC output configurable as current-based signal (4 to 20 mA) or voltage-based signal (±5V) per dynamic channel
      • 2 configurable SPDT relays, and alarm reset (AR), alarm bypass (AB) and trip multiply (TM) control inputs
    Compare
  • VibroSmart® VSB010 terminal base for VSI010 module
    • VibroSmart® VSB010 terminal base for VSI010 module
    • VibroSmart® VSB010 terminal base for VSI010 module
      • Input/output (interface) terminal base for a VSI010 module – supports 2 fieldbus interfaces
      • Up to 2 serial fieldbus interfaces (Modbus RTU or PROFIBUS DP) with VSF001 serial fieldbus communications adaptor
      • PROFIsafe safety layer to ensure more reliable PROFIBUS communications
      • 1 Ethernet fieldbus interface (Modbus TCP) with VSF002 Ethernet fieldbus communications adaptor
      • 2 configurable SPDT relays, and alarm reset (AR), alarm bypass (AB), trip multiply (TM) and fieldbus communication stop (FBCS) control inputs
    Compare
  • VibroSmart® VSA301 buffered output amplifier
    • VibroSmart® VSA301 buffered output amplifier
    • VibroSmart® VSA301 buffered output amplifier
      • Designed for operation with the VSV300 monitoring module
      • Two dynamic channels with current or voltage inputs, AC or DC coupling, fixed-gain amplification of 10, and voltage and current outputs
      • One tachometer channel with current or voltage input, offset removal, 3.3 to 5.0 V digital level translation and a voltage output
      • Voltage signal transmission over short distances, up to 5 m
      • Current signal transmission over long distances, up to 500 m
    Compare
  • VibroSmart® VSN010 real-time Ethernet switch
    • VibroSmart® VSN010 real-time Ethernet switch
    • VibroSmart® VSN010 real-time Ethernet switch
      • Real-time Ethernet switch providing fault-tolerant protocol redundancy for networks
      • Redundant real-time communications based on high-availability seamless redundancy (HSR, IEC 62439-3) with zero recovery time
      • Redundant non-real-time communications based on the rapid spanning tree protocol (RSTP, IEEE 802.1D)
      • Enables cost-effective redundant networks of VibroSmart modules, with zero time to recovery for a single point of failure
      • Allows VibroSmart modules to be arranged in a HSR ring network topology for increased system availability
    Compare
  • VibroSmart® VSF001 serial fieldbus communications adaptor
    • VibroSmart® VSF001 serial fieldbus communications adaptor
    • VibroSmart® VSF001 serial fieldbus communications adaptor
      • Designed for operation with the VSI010 communications interface module
      • Serial fieldbus communications adaptor with two 9-pin D-sub connectors
      • Supports serial-based fieldbuses (communications protocols) such as Modbus RTU and PROFIBUS DP
      • Plugs into the J5 and J6 screw-terminal connectors on the VSB010 terminal base used by the VSI010 module
    Compare
  • VibroSmart® VSF002 Ethernet fieldbus communications adaptor
    • VibroSmart® VSF002 Ethernet fieldbus communications adaptor
    • VibroSmart® VSF002 Ethernet fieldbus communications adaptor
      • Designed for operation with the VSI010 communications interface module
      • Ethernet fieldbus communications adaptor with two 8P8C (RJ45) connectors
      • Supports Ethernet-based fieldbuses (communications protocols) such as Modbus TCP
      • Plugs into the J4 screw-terminal connector on the VSB010 terminal base used by the VSI010 module
    Compare
  • VibroSmart® VSA005 19″ rack mounting BNC patch panel
    • VibroSmart® VSA005 19″ rack mounting BNC patch panel
    • VibroSmart® VSA005 19″ rack mounting BNC patch panel
      • Designed for operation with the VSV300 monitoring module
      • Patch panel for use with the VSA003 cable assembly
      • 19″ rack mounting BNC patch panel with 21 slots
      • Each BNC patch panel slot supports supports three channels (one VSV300 module)
    Compare
  • VibroSmart® VSA004 DIN rail mounting BNC patch panel
    • VibroSmart® VSA004 DIN rail mounting BNC patch panel
    • VibroSmart® VSA004 DIN rail mounting BNC patch panel
      • Designed for operation with the VSV300 monitoring module
      • Patch panel for use with the VSA003 cable assembly
      • DIN rail mounting BNC patch panel with 10 slots
      • Each BNC patch panel slot supports supports three channels (one VSV300 module)
    Compare
  • VibroSmart® VSA003 BNC cable assembly with female BNC connectors
    • VibroSmart® VSA003 BNC cable assembly with female BNC connectors
    • VibroSmart® VSA003 BNC cable assembly with female BNC connectors
      • Designed for operation with the VSV300 monitoring module
      • Cable assembly for use with VSA004 and VSA005 BNC patch panels
      • Connect the buffered transducer outputs available from the J2 connector of a VSV300 module / VSB300 terminal base to other systems
      • Each cable assembly supports three channels (one VSV300 module)
    Compare
  • VibroSmart® VSA002 BNC cable assembly with male BNC connectors
    • VibroSmart® VSA002 BNC cable assembly with male BNC connectors
    • VibroSmart® VSA002 BNC cable assembly with male BNC connectors
      • Designed for operation with the VSV300 monitoring module
      • Cable assembly for use with standard test and measurement equipment
      • Connect the buffered transducer outputs available from the J2 connector of a VSV300 module / VSB300 terminal base to other systems
      • Each cable assembly supports three channels (one VSV300 module)
