VM600 MPC4SIL machinery protection card
- 4 dynamic channels
- 2 processed outputs per dynamic channel and 1 processed output per dual-channel (2 per MPC4)
- Highly configurable card supports a subset of SIL 1 approved measurements for machinery protection, including relative and/or absolute vibration
- Highly integrated card pair (with IOC4T) includes sensor power supplies, buffered outputs, DC outputs, relays and serial communications interfaces
- Designed for operation with the VM600 MPSx software
Description
High-quality, high-reliability machinery protection card – with SIL 1 approval – for VM600 rack-based machinery monitoring systems. The MPC4 card provides 4 dynamic channels, all of which are independently configurable. An MPC4SIL machinery protection card is installed in the front of a VM600 ABE04x rack and requires an IOC4T card to form a card pair.
Features
- 4 dynamic channels
- 2 processed outputs per dynamic channel and 1 processed output per dual-channel (2 per MPC4)
- Highly configurable card supports a subset of SIL 1 approved measurements for machinery protection, including relative and/or absolute vibration
- Highly integrated card pair (with IOC4T) includes sensor power supplies, buffered outputs, DC outputs, relays and serial communications interfaces
- Designed for operation with the VM600 MPSx software
Additional information
| Monitoring system (application) | Machinery protection |
|---|---|
| VM600 system function | Machinery protection |
| VM600 system component | Processing card |
| VM600 component function | Machinery protection |
| VM600 component and rack compatibility | ABE040, ABE042 |
| VM600 card measurement channels | 4 dynamic channels |
Sorry, there are no downloads currently available for this product
